链条吊索 Grade 80 SOSL

1 点式钢

产品概述
80级 SOSL 链索 — 单腿，上部带椭圆主环，底部带销轴自锁（安全）钩。包含索具样式标识、单独序列号、链径与级别、确切索长及工作载荷限值。

简介

• S = Sling Leg
• T = Triple Leg
• S = Sling Hook (w/latch)
• SL = Self Locking (Safety) Hook
• F = Foundry Hook
• D = Double Leg
• Q = Quad Leg
• G = Grab Hook
• O = Oblong Master Link

链索随附书面合格证。标签上的序列号将与证书和销售订单号对应，以确保完整的可追溯性。

参数（表）
Design Factor | 1-Leg Sling | 2-Leg Sling | 3-Leg & 4-Leg Slings
Chain Diameter | 90 Degrees | 60 Degrees | 45 Degrees | 30 Degrees | 60 Degrees | 45 Degrees | 30 Degrees
Load Factor: | 1 | 1.7 | 1.4 | 1 | 2.6 | 2.1 | 1.45
7/32" | 2,100 | 3,600 | 3,000 | 2,100 | 5,500 | 4,400 | 3,200
9/32" | 3,500 | 6,100 | 4,900 | 3,500 | 9,100 | 7,400 | 5,200
5/16" | 4,500 | 7,800 | 6,400 | 4,500 | 11,700 | 9,500 | 6,800
3/8" | 7,100 | 12,300 | 10,000 | 7,100 | 18,400 | 15,100 | 10,600
1/2" | 12,000 | 20,800 | 17,000 | 12,000 | 31,200 | 25,500 | 18,000
5/8" | 18,100 | 31,300 | 25,600 | 18,100 | 47,000 | 38,400 | 27,100
3/4" | 28,300 | 49,000 | 40,000 | 28,300 | 73,500 | 60,000 | 42,400
7/8" | 34,200 | 59,200 | 48,400 | 34,200 | 88,900 | 72,500 | 51,300
1" | 47,700 | 82,600 | 67,400 | 47,700 | 123,900 | 101,200 | 71,500
1-1/4" | 72,300 | 125,200 | 102,200 | 72,300 | 187,800 | 153,400 | 108,500

标准
名称: Grade 80 SOSL Chain Sling — Single Leg w/ Oblong Master Link on Top and Clevis Self Locking Hook on Bottom
最小起订量: 100 米
包装: 纸箱 + 钢托盘

技术规格

• 品牌: TOPONE CHAIN
• 商业名称: Grade 80 SOSL Chain Sling
• 等级: Grade 80
• 索具配置: 单腿（可选双腿、三腿、四腿）
• 上部配件: 椭圆主环
• 下部配件: 销轴自锁（安全）钩 (SL)
• 序列号: 标签上有单独序列号；提供书面认证以确保可追溯性
• 设计系数: 4:1
• 可选链径: 7/32", 9/32", 5/16", 3/8", 1/2", 5/8", 3/4", 7/8", 1", 1-1/4"
• 工作载荷限值: 按链径和吊装角度提供（见参数块）
• MOQ: 100 米
• 包装: 纸箱加钢托盘
