电缆滚动导卫装置 UR series滑动移门钩形双
添加到我的收藏夹
添加到产品对比表
产品规格型号
- 应用
- 用于电缆, 滑动移门
- 硬化速度
- 双, 钩形
产品介绍
概述型号URH - 高轮廓滑块架：加高设计实现特别坚固和刚性的导向，增加高度实现最佳的力吸收和高稳定性。有重型和超重型可供选择。 URL - 扁平式滑块台车：低轮廓设计，适用于紧凑型机器布局；导向稳定、坚固，安装空间最小。有重型和超重型可供选择。 URW - 法兰块台车：宽支撑面，用于非常稳定的抗扭转安装；适用于需要最大稳定性和灵活安装选项的场合。有重型和超重型可供选择。
特点 滚柱导轨设计经过优化，具有极高的动态和静态承载能力。 获得专利的 360° 润滑油分布，可在所有安装位置提供可靠的润滑，并降低润滑油消耗量。 防污密封系统可在恶劣的工业环境中提供保护。 多种缸体类型（高轮廓、扁平、法兰），以适应不同的安装限制。 可提供重载和超重载应用配置。 提供用于配置和下载的 CAD 模型和技术图纸。
特征/技术参数 表头：H [mm]; W [mm]; L [mm]; Cdyn [N]; C0 [N]; H1 [mm]; N [mm]; B [mm]; B1 [mm]; C [mm]; L1 [mm]; K1 [mm]; K2 [mm]；G [mm]; M; l [mm]; T [mm]; H2 [mm]; H3 [mm]; Mass [kg]; M0X [Nm]; M0Y [Nm]; M0Z [Nm] URH35CA：H=55；W=70；L=124；Cdyn=61。200 N; C0=127.500 N; H1=7 mm; N=18 mm; B=50 mm; B1=10 mm; C=50 mm; L1=79 mm; K1=24,5 mm; K2=14 mm; G=12,2 mm; M=M8; l=12 mm; T=12 mm; H2=14,9 mm; H3=14,9 mm; Mass=1,6 kg; M0X=2.720 Nm; M0Y=1.820 Nm; M0Z=1.820 Nm URH35CA: H=55; W=70; L=124; Cdyn=61.
URH35HA: H=55; W=70; L=151,5; Cdyn=75.400 N; C0=172.100 N; H1=7 mm; N=18 mm; B=50 mm; B1=10 mm; C=72 mm; L1=106,5 mm; K1=37,25 mm; K2=14 mm; G=12,2 mm; M=M8; l=12 mm; T=12 mm; H2=14,9 mm; H3=14,9 mm; Mass=2,09 kg; M0X=3.670 Nm; M0Y=3.210 Nm; M0Z=3.210 Nm URH45CA: H=55; W=70; L=151,5; Cdyn=75.400 N; C0=172.
URH45CA: H=70; W=86; L=153,4; Cdyn=110.400 N; C0=239.600 N; H1=8 mm; N=205 mm; B=60 mm; B1=13 mm; C=60 mm; L1=107,2 mm; K1=34,6 mm; K2=12,1 mm; G=12,2 mm; M=M10; l=19 mm; T=17 mm; H2=20 mm; H3=20 mm; Mass=3,21 kg; M0X=6.380 Nm; M0Y=4.580 Nm; M0Z=4.580 Nm URH45CA: H=70; W=86; L=153,4; Cdyn=110.400 Nm; C0=239.
URH45HA: H=70; W=86; L=187; Cdyn=134.800 N; C0=309.500 N; H1=8 mm; N=205 mm; B=60 mm; B1=13 mm; C=80 mm; L1=140,8 mm; K1=41,4 mm; K2=12,1 mm; G=12,2 mm; M=M10; l=19 mm; T=17 mm; H2=20 mm; H3=20 mm; Mass=4,15 kg; M0X=8.240 Nm; M0Y=7.430 Nm; M0Z=7.430 Nm URH45HA: H=70; W=86; L=187; Cdyn=134.800 Nm; C0=309.
URH55CA: H=80; W=100; L=153,4; Cdyn=144.000 N; C0=336.000 N; H1=10 mm; N=235 mm; B=75 mm; B1=12,5 mm; C=75 mm; L1=125,5 mm; K1=35,75 mm; K2=12,5 mm; G=12,2 mm; M=M12; l=18 mm; T=18,5 mm; H2=19,5 mm; H3=19,5 mm; Mass=4,61 kg; M0X=10.370 Nm; M0Y=7.390 Nm; M0Z=7.390 Nm
URH55HA: H=80; W=100; L=224,5; Cdyn=185.500 N; C0=467.600 N; H1=10 mm; N=235 mm; B=75 mm; B1=12,5 mm; C=95 mm; L1=175,3 mm; K1=50,65 mm; K2=12,5 mm; G=12,2 mm; M=M12; l=18 mm; T=18,5 mm; H2=19,5 mm; H3=19,5 mm; Mass=6,37 kg; M0X=14.430 Nm; M0Y=14.340 Nm; M0Z=14.340 Nm
URL35CA: H=48; W=70; L=124; Cdyn=61.200 N; C0=127.500 N; H1=7 mm; N=18 mm; B=50 mm; B1=10 mm; C=50 mm; L1=79 mm; K1=24,5 mm; K2=14 mm; G=12,2 mm; M=M8; l=12 mm; T=12 mm; H2=7,9 mm; H3=7,9 mm; Mass=1,29 kg; M0X=2.720 Nm; M0Y=1.820 Nm; M0Z=1.820 Nm URL35CA: H=48; W=70; L=124; Cdyn=61.200 N; C0=127.
URL35HA: H=48; W=70; L=151,5; Cdyn=75.400 N; C0=172.100 N; H1=7 mm; N=18 mm; B=50 mm; B1=10 mm; C=72 mm; L1=106,5 mm; K1=37,25 mm; K2=14 mm; G=12,2 mm; M=M8; l=12 mm; T=12 mm; H2=7,9 mm; H3=7,9 mm; Mass=1,67 kg; M0X=3.670 Nm; M0Y=3.210 Nm; M0Z=3.210 Nm URL45CA: H=60; W=86; L=153,4; Cdyn=110.400 N; C0=239.
URL45HA: H=60; W=86; L=187; Cdyn=134.800 N; C0=309.500 N; H1=8 mm; N=20,5 mm; B=60 mm; B1=13 mm; C=80 mm; L1=140,8 mm; K1=41,4 mm; K2=12,1 mm; G=12,2 mm; M=M10; l=17 mm; T=17 mm; H2=10 mm; H3=10 mm; 质量=3,24 kg; M0X=8.240 Nm; M0Y=7.430 Nm; M0Z=7.430 Nm URL55CA: H=60; W=86; L=187; Cdyn=134.800 Nm; C0=309.500 Nm
URL55CA: H=70; W=100; L=153,4; Cdyn=144.000 N; C0=336.000 N; H1=10 mm; N=20,5 mm; B=60 mm; B1=13 mm; C=60 mm; L1=107,2 mm; K1=34,6 mm; K2=12,1 mm; G=12,2 mm; M=M10; l=17 mm; T=17 mm; H2=10 mm; H3=10 mm; Mass=2,52 kg; M0X=6.380 Nm; M0Y=4.580 Nm; M0Z=4.580 Nm URL55CA: H=70; W=100; L=153,4; Cdyn=144.000 N; C0=336.
URL55HA: H=70; W=100; L=224,5; Cdyn=185.500 N; C0=467.600 N; H1=10 mm; N=23,5 mm; B=75 mm; B1=12,5 mm; C=75 mm; L1=125,5 mm; K1=35,75 mm; K2=12,5 mm; G=12,2 mm; M=M12; l=17 mm; T=17,5 mm; H2=10 mm; H3=10 mm; Mass=3,67 kg; M0X=10.370 Nm; M0Y=7.390 Nm; M0Z=7.390 Nm URW35CC: H=70; W=100; L=224,5; Cdyn=185.500 N; C0=467.
URW35CC: H=48; W=100; L=124; Cdyn=61.200 N; C0=127.500 N; H1=7 mm; N=33 mm; B=82 mm; B1=9 mm; C=62 mm; L1=79 mm; K1=18,5 mm; K2=14 mm; G=12,2 mm; M=M10; l= (未指定); T=12 mm; H2=7,9 mm; H3=7,9 mm; Mass=1,8 kg; M0X=2.720 Nm; M0Y=1.820 Nm; M0Z=1.820 Nm URW35HC: H=48; W=100; L=124; Cdyn=61.200 N; C0=127.
URW35HC: H=48; W=100; L=151,5; Cdyn=75.400 N; C0=172.100 N; H1=7 mm; N=33 mm; B=82 mm; B1=9 mm; C=62 mm; L1=106,5 mm; K1=32,25 mm; K2=14 mm; G=12,2 mm; M=M10; l= (未指定); T=12 mm; H2=7,9 mm; H3=7,9 mm; Mass=2,43 kg; M0X=3.670 Nm; M0Y=3.210 Nm; M0Z=3.210 Nm URW45CC: H=48; W=100; L=151,5; Cdyn=75.400 N; C0=172.
URW45CC: H=60; W=120; L=153,4; Cdyn=110.400 N; C0=239.600 N; H1=8 mm; N=33,5 mm?B=116 mm; B1=10 mm; C=80 mm; L1=107,2 mm; K1=24,6 mm; K2=12,1 mm; G=12,2 mm; M=M12; l= (未说明); T=14 mm; H2=10 mm; H3=10 mm; 质量=3,47 kg; M0X=6.380 Nm; M0Y=4.580 Nm; M0Z=4.580 Nm
URW45HC: H=60; W=120; L=187; Cdyn=134.800 N; C0=309.500 N; H1=8 mm; N=375 mm; B=100 mm; B1=10 mm; C=80 mm; L1=140,8 mm; K1=41,4 mm; K2=12,1 mm; G=12,2 mm; M=M12; l= (未指定); T=14 mm; H2=10 mm; H3=10 mm; Mass=4,58 kg; M0X=8.240 Nm; M0Y=7.430 Nm; M0Z=7.430 Nm URW45HC: H=60; W=120; L=187; Cdyn=134.800 Nm; C0=309.
URW55CC: H=70; W=140; L=174,7; Cdyn=144.000 N; C0=336.000 N; H1=10 mm; N=435 mm; B=116 mm; B1=12 mm; C=95 mm; L1=125,5 mm; K1=25,75 mm; K2=12,5 mm; G=12,2 mm; M=M14; l=（未指定）; T=16 mm; H2=9,6 mm; H3=9,6 mm; Mass=5,16 kg; M0X=10.370 Nm; M0Y=7.390 Nm; M0Z=7.390 Nm
URW55HC: H=70; W=140; L=224,5; Cdyn=185.500 N; C0=467.600 N; H1=10 mm; N=435 mm; B=116 mm; B1=12 mm; C=95 mm; L1=175,3 mm; K1=50,65 mm; K2=12,5 mm; G=12,2 mm; M=M14; l= (未注明); T=16 mm; H2=9,6 mm; H3=9,6 mm; Mass=7,31 kg; M0X=14.430 牛米； M0Y=14.340 牛米； M0Z=14.340 牛米 。
---
