墙面式盒 WG series用于面板安装模块化塑料
添加到我的收藏夹
添加到产品对比表
产品规格型号
- 配置
- 墙面式, 用于面板安装
- 形状
- 模块化
- 材料
- 塑料
- 应用
- 户外, 网络, 远程通信, 车用, 用于汽车
- 保护水平
- 防风雨, 防紫外线, 阻燃, 坚固
- 其他特性
- 设计, 带格兰头, 防护
- 宽度
最少: 100 mm
(3.9 in)最多: 300 mm
(11.8 in)- 高度
最少: 55 mm
(2.2 in)最多: 150 mm
(5.9 in)- 深度
最少: 150 mm
(5.91 in)最多: 400 mm
(15.75 in)
产品介绍
概述
IP68 塑料外壳，设计可承受 1m 深度浸没达 24 小时。适用于需要高等级防护的户外通信和网络设备。
主要特性
系列分类
产品编号 / 尺寸（摘自产品表）
Product No.: WG10-15-6W | External W x D x H (mm): 100 x 150 x 55 | Internal w x d x h (mm): 63 x 115 x 43 | Material: ASA (UL94HB) | Weight (g): 169.5
Product No.: WG10-15-8W | External: 100 x 150 x 75 | Internal: 75 x 62 x 114 | Material: ASA (UL94HB) | Weight (g): 192
Product No.: WG15-16-6W | External: 145 x 155 x 55 | Internal: 107 x 120 x 43 | Material: ASA (UL94HB) | Weight (g): 232
Product No.: WG15-16-8W | External: 145 x 155 x 80 | Internal: 80 x 105 x 118 | Material: ASA (UL94HB) | Weight (g): 266.5
Product No.: WG15-21-6W | External: 145 x 210 x 60 | Internal: 107 x 174 x 48 | Material: ASA (UL94HB) | Weight (g): 314
Product No.: WG15-21-9W | External: 145 x 210 x 90 | Internal: 105 x 172 x 78 | Material: ASA (UL94HB) | Weight (g): 367
Product No.: WG17-25-8W | External: 170 x 250 x 80 | Internal: 128 x 209 x 67.5 | Material: ASA (UL94HB) | Weight (g): 470
Product No.: WG17-25-11W | External: 170 x 250 x 110 | Internal: 125 x 206 x 97.5 | Material: ASA (UL94HB) | Weight (g): 534
Product No.: WG23-25-8W | External: 225 x 245 x 80 | Internal: 183 x 194 x 67.5 | Material: ASA (UL94HB) | Weight (g): 570
Product No.: WG23-25-11W | External: 225 x 245 x 110 | Internal: 180 x 191 x 97.5 | Material: ASA (UL94HB) | Weight (g): 645
Product No.: WG25-33-9W | External: 245 x 325 x 90 | Internal: 192 x 268 x 74 | Material: ASA (UL94HB) | Weight (g): 965
Product No.: WG25-33-12W | External: 245 x 325 x 120 | Internal: 189 x 265 x 104 | Material: ASA (UL94HB) | Weight (g): 1073
Product No.: WG30-33-9W | External: 300 x 325 x 90 | Internal: 247 x 268 x 74 | Material: ASA (UL94HB) | Weight (g): 1151
Product No.: WG30-33-13W | External: 300 x 325 x 130 | Internal: 243 x 264 x 114 | Material: ASA (UL94HB) | Weight (g): 1285.5
Product No.: WG28-40-10W | External: 280 x 400 x 100 | Internal: 226 x 338 x 84 | Material: ASA (UL94HB) | Weight (g): 1332.5
Product No.: WG28-40-15W | External: 280 x 400 x 150 | Internal: 220 x 332 x 134 | Material: ASA (UL94HB) | Weight (g): 1529.5
Product No.: WGPC 10-15-6G | External: 100 x 150 x 55 | Internal: 63 x 115 x 43 | Material: PC+ASA (UL94V-0) | Weight (g): 188.5
Product No.: WGPC 10-15-8G | External: 100 x 150 x 75 | Internal: 75 x 62 x 114 | Material: PC+ASA (UL94V-0) | Weight (g): 213.5
Product No.: WGPC 15-16-6G | External: 145 x 155 x 55 | Internal: 107 x 120 x 43 | Material: PC+ASA (UL94V-0) | Weight (g): 258
Product No.: WGPC 15-16-8G | External: 145 x 155 x 80 | Internal: 80 x 105 x 118 | Material: PC+ASA (UL94V-0) | Weight (g): 296.5
Product No.: WGPC 15-21-6G | External: 145 x 210 x 60 | Internal: 107 x 174 x 48 | Material: PC+ASA (UL94V-0) | Weight (g): 349.5
Product No.: WGPC 15-21-9G | External: 145 x 210 x 90 | Internal: 105 x 172 x 78 | Material: PC+ASA (UL94V-0) | Weight (g): 408.5
Product No.: WGPC 17-25-8G | External: 170 x 250 x 80 | Internal: 128 x 209 x 67.5 | Material: PC+ASA (UL94V-0) | Weight (g): 523
Product No.: WGPC 17-25-11G | External: 170 x 250 x 110 | Internal: 125 x 206 x 97.5 | Material: PC+ASA (UL94V-0) | Weight (g): 594
Product No.: WGPC 23-25-8G | External: 225 x 245 x 80 | Internal: 183 x 194 x 67.5 | Material: PC+ASA (UL94V-0) | Weight (g): 634
Product No.: WGPC 23-25-11G | External: 225 x 245 x 110 | Internal: 180 x 191 x 97.5 | Material: PC+ASA (UL94V-0) | Weight (g): 717.5
Product No.: WGPC 25-33-9G | External: 245 x 325 x 90 | Internal: 192 x 268 x 74 | Material: PC+ASA (UL94V-0) | Weight (g): 1073.5
Product No.: WGPC 25-33-12G | External: 245 x 325 x 120 | Internal: 189 x 265 x 104 | Material: PC+ASA (UL94V-0) | Weight (g): 1193.5
Product No.: WGPC 30-33-9G | External: 300 x 325 x 90 | Internal: 247 x 268 x 74 | Material: PC+ASA (UL94V-0) | Weight (g): 1280
Product No.: WGPC 30-33-13G | External: 300 x 325 x 130 | Internal: 243 x 264 x 114 | Material: PC+ASA (UL94V-0) | Weight (g): 1430
Product No.: WGPC 28-40-10G | External: 280 x 400 x 100 | Internal: 226 x 338 x 84 | Material: PC+ASA (UL94V-0) | Weight (g): 1482
Product No.: WGPC 28-40-15G | External: 280 x 400 x 150 | Internal: 220 x 332 x 134 | Material: PC+ASA (UL94V-0) | Weight (g): 1701
可选部件 / 配件
规格 / 技术参数
IP68 塑料外壳，设计可承受 1m 深度浸没达 24 小时。适用于需要高等级防护的户外通信和网络设备。
主要特性
- 硅胶防水垫圈与背部多点固定螺钉结合，保持稳定的 IP68 防护性能。
- 自攻式固定螺钉在预钻孔中切削螺纹，从而可靠地固定盖与本体，无需额外攻丝工序。
- 提供 16 种尺寸，分为 WG（ASA）和 WGPC（PC+ASA，阻燃）两种材质系列。
- ASA 对紫外线具有抗性，可减少户外使用中的劣化与变色。
- 可选安装附件支持墙体与杆件安装；可选 WTB 接线端子可安装于 WG 内部现有凸台，无需额外加工。
系列分类
- WG series (ASA)
- WGPC series (PC+ASA, flame-retardant)
产品编号 / 尺寸（摘自产品表）
Product No.: WG10-15-6W | External W x D x H (mm): 100 x 150 x 55 | Internal w x d x h (mm): 63 x 115 x 43 | Material: ASA (UL94HB) | Weight (g): 169.5
Product No.: WG10-15-8W | External: 100 x 150 x 75 | Internal: 75 x 62 x 114 | Material: ASA (UL94HB) | Weight (g): 192
Product No.: WG15-16-6W | External: 145 x 155 x 55 | Internal: 107 x 120 x 43 | Material: ASA (UL94HB) | Weight (g): 232
Product No.: WG15-16-8W | External: 145 x 155 x 80 | Internal: 80 x 105 x 118 | Material: ASA (UL94HB) | Weight (g): 266.5
Product No.: WG15-21-6W | External: 145 x 210 x 60 | Internal: 107 x 174 x 48 | Material: ASA (UL94HB) | Weight (g): 314
Product No.: WG15-21-9W | External: 145 x 210 x 90 | Internal: 105 x 172 x 78 | Material: ASA (UL94HB) | Weight (g): 367
Product No.: WG17-25-8W | External: 170 x 250 x 80 | Internal: 128 x 209 x 67.5 | Material: ASA (UL94HB) | Weight (g): 470
Product No.: WG17-25-11W | External: 170 x 250 x 110 | Internal: 125 x 206 x 97.5 | Material: ASA (UL94HB) | Weight (g): 534
Product No.: WG23-25-8W | External: 225 x 245 x 80 | Internal: 183 x 194 x 67.5 | Material: ASA (UL94HB) | Weight (g): 570
Product No.: WG23-25-11W | External: 225 x 245 x 110 | Internal: 180 x 191 x 97.5 | Material: ASA (UL94HB) | Weight (g): 645
Product No.: WG25-33-9W | External: 245 x 325 x 90 | Internal: 192 x 268 x 74 | Material: ASA (UL94HB) | Weight (g): 965
Product No.: WG25-33-12W | External: 245 x 325 x 120 | Internal: 189 x 265 x 104 | Material: ASA (UL94HB) | Weight (g): 1073
Product No.: WG30-33-9W | External: 300 x 325 x 90 | Internal: 247 x 268 x 74 | Material: ASA (UL94HB) | Weight (g): 1151
Product No.: WG30-33-13W | External: 300 x 325 x 130 | Internal: 243 x 264 x 114 | Material: ASA (UL94HB) | Weight (g): 1285.5
Product No.: WG28-40-10W | External: 280 x 400 x 100 | Internal: 226 x 338 x 84 | Material: ASA (UL94HB) | Weight (g): 1332.5
Product No.: WG28-40-15W | External: 280 x 400 x 150 | Internal: 220 x 332 x 134 | Material: ASA (UL94HB) | Weight (g): 1529.5
Product No.: WGPC 10-15-6G | External: 100 x 150 x 55 | Internal: 63 x 115 x 43 | Material: PC+ASA (UL94V-0) | Weight (g): 188.5
Product No.: WGPC 10-15-8G | External: 100 x 150 x 75 | Internal: 75 x 62 x 114 | Material: PC+ASA (UL94V-0) | Weight (g): 213.5
Product No.: WGPC 15-16-6G | External: 145 x 155 x 55 | Internal: 107 x 120 x 43 | Material: PC+ASA (UL94V-0) | Weight (g): 258
Product No.: WGPC 15-16-8G | External: 145 x 155 x 80 | Internal: 80 x 105 x 118 | Material: PC+ASA (UL94V-0) | Weight (g): 296.5
Product No.: WGPC 15-21-6G | External: 145 x 210 x 60 | Internal: 107 x 174 x 48 | Material: PC+ASA (UL94V-0) | Weight (g): 349.5
Product No.: WGPC 15-21-9G | External: 145 x 210 x 90 | Internal: 105 x 172 x 78 | Material: PC+ASA (UL94V-0) | Weight (g): 408.5
Product No.: WGPC 17-25-8G | External: 170 x 250 x 80 | Internal: 128 x 209 x 67.5 | Material: PC+ASA (UL94V-0) | Weight (g): 523
Product No.: WGPC 17-25-11G | External: 170 x 250 x 110 | Internal: 125 x 206 x 97.5 | Material: PC+ASA (UL94V-0) | Weight (g): 594
Product No.: WGPC 23-25-8G | External: 225 x 245 x 80 | Internal: 183 x 194 x 67.5 | Material: PC+ASA (UL94V-0) | Weight (g): 634
Product No.: WGPC 23-25-11G | External: 225 x 245 x 110 | Internal: 180 x 191 x 97.5 | Material: PC+ASA (UL94V-0) | Weight (g): 717.5
Product No.: WGPC 25-33-9G | External: 245 x 325 x 90 | Internal: 192 x 268 x 74 | Material: PC+ASA (UL94V-0) | Weight (g): 1073.5
Product No.: WGPC 25-33-12G | External: 245 x 325 x 120 | Internal: 189 x 265 x 104 | Material: PC+ASA (UL94V-0) | Weight (g): 1193.5
Product No.: WGPC 30-33-9G | External: 300 x 325 x 90 | Internal: 247 x 268 x 74 | Material: PC+ASA (UL94V-0) | Weight (g): 1280
Product No.: WGPC 30-33-13G | External: 300 x 325 x 130 | Internal: 243 x 264 x 114 | Material: PC+ASA (UL94V-0) | Weight (g): 1430
Product No.: WGPC 28-40-10G | External: 280 x 400 x 100 | Internal: 226 x 338 x 84 | Material: PC+ASA (UL94V-0) | Weight (g): 1482
Product No.: WGPC 28-40-15G | External: 280 x 400 x 150 | Internal: 220 x 332 x 134 | Material: PC+ASA (UL94V-0) | Weight (g): 1701
可选部件 / 配件
- MOUNTING PLATE for WG・WGPC・WGV
- TERMINAL BLOCK - WTB series
- WALL MOUNTING BRACKET for WG・WGPC・WGV
- POLE MOUNTING BRACKET for WG・WGPC・WGV
- DIECAST ALUMINIUM POLE MOUNTING BRACKET
- STAINLESS STEEL TIES - SCT series
- STAINLESS STEEL POLE MOUNTING STRAP - SNB series
- POLE MOUNTING BELT - PKB series
- PROTECTIVE VENT - PMF series
- IP68 CABLE GLAND - AG series
- WEATHERPROOF CABLE GLAND - RMW series
- STRAIN RELIEF CABLE GLAND - RSP series
- DIN RAIL for WG・WGPC・WGV
- PCB MOUNTING SCREW for WG・WGPC・WGV - MT4-8T
- TAPPING STANDOFF - TPS series
- INSERT NUT ADHESIVE STANDOFF - AST series
- ADHESIVE PCB STANDOFF - ASR series
- VENTILATION PLUG - CVP series
规格 / 技术参数
- 防护等级：IP68（浸没至 1 m，24 小时）
- 防水密封：硅胶防水垫圈
- 固定方式：背部多颗固定螺钉；自攻式固定螺钉
- 尺寸：WG 与 WGPC 系列共 16 种尺寸（见产品编号 / 尺寸）
- 材质：WG = 抗紫外线 ASA（UL94HB）；WGPC = 抗紫外线 PC/ASA（UL94V-0）
- 工作温度：WG -30°C 至 +60°C；WGPC -30°C 至 +75°C
- 颜色：WG 近米白（类似 Munsell N8.75）；WGPC 近浅灰（类似 PANTONE427C）
- 抗紫外线：ASA 抵抗紫外线引致的劣化与变色
- 安装选项：可通过选配支架和附件实现墙装和杆装
- 可选接线端子：WTB 系列可直接安装于 WG 内部现有凸台，无需加工
- 可用文档：目录、按型号 PDF、IP68 测试证书、耐候性测试数据
