IP呼叫亭 KNPA800miniR

PoE以太网4.3"

Overview
Model: KNPA800miniR
Size: 213 (L) x 190 (W) x 76 (H) mm (excluding microphone)
Material: ABS (Acrylonitrile Butadiene Styrene)

Product Summary
PA CALL STATION / PAGING MICROPHONE designed for professional PA applications and mission-critical voice evacuation systems. Supports 100-zone one-touch paging with a covered red emergency key and is supplied with a gooseneck unidirectional microphone.

Key Functional Features & Benefits

• Purpose-built for uncompromising reliability and certified safety (EN 54-16 and ISO 7240-16).
• Engineered for professional excellence to ensure performance and longevity in demanding environments.
• 24/7 operational readiness with intelligent energy-saving features in standby mode.
• User-centric interface with a vibrant 4.3-inch TFT for clear, responsive control and simplified operation.
• Effortless zone & group selection: configure and select individual zones, predefined groups, or initiate all-call broadcasts through the expandable display.
• Clear visual indicators for power, communication status, and push-to-talk activation for immediate status confirmation.
• Superior audio management with a professional-grade gooseneck unidirectional microphone optimized for voice clarity in noisy environments.
• Total audio control: adjustable microphone sensitivity, volume control, and software-configurable parametric equalization.
• Seamless integration of external audio via a 3.5mm jack for wireless microphone input.
• Flexible broadcasting: selective zone, group-zone and all-call paging; automated/scheduled announcements and pre-recorded messages supported.
• Emergency priority routing: emergency announcements override lower-priority audio automatically.
• Enterprise-grade reliability: Power over Ethernet (PoE) operation and dual Ethernet ports for network redundancy.
• Secure and encrypted communication using AES67 for audio and AES70 for control.

Specification Highlights

• 100-zone one-touch paging with a guarded red emergency key (10 pages × 10 physical paging buttons, 4 function keys, one main paging key).
• Gooseneck unidirectional microphone with momentary (non-locking) PTT button.
• 4.3" TFT color display for zone selection, call status and fault indication.
• Built-in chime tone playback prior to live paging (configurable enable/disable).
• Concurrent live paging support for non-overlapping zones; zone conflict handling with priority/occupancy policy.
• BGM & live paging mixing with ducking support.
• Zone-based paging with flexible and quick zone operations.
• System monitoring for power, communication and fault indication with acknowledge/mute support.
• Supports secure access control and configurable user privileges; aligns with IEC 62443 cybersecurity requirements.
• Front panel protection: IP22 (minimum, for indoor control room environment).
• Mounting: Desktop, Wall Mount, Flush (Panel) Mount (cut-out dimensions and mounting brackets optional).

System & Integration
Designed as a professional IP Network Paging Console for PAGA/PA systems intended for safe-area control rooms and operation centers. Enables zone paging, emergency paging activation and system status monitoring. Integrates with PAGA controllers/servers for alarm inputs, external alarm indication and encrypted control to prevent unauthorized access.

Area of Use
Intended for safe-area control room applications. For hazardous areas, IECEx/ATEX certified field devices should be used as required.

More Features and Positioning

• One-touch emergency paging with anti-misoperation protection (covered flip cover on emergency key).
• Manual alarm/emergency paging: General Alarm / Gas Alarm / All Clear; supports press-and-hold or confirmation pop-up (configurable).
• User privilege control to restrict emergency/alarm operations to authorized users only.
• Local and external alarm indication displayed on the 4.3" TFT with acknowledge/mute support.

Caractéristiques / Spécifications techniques

• Modèle : KNPA800miniR
• Taille : 213 × 190 × 76 mm (L × W × H) (excl. microphone)
• Matériau : ABS
• Certifications : EN 54-16, ISO 7240-16
• Zones : 100-zone one-touch paging (10 pages × 10 buttons)
• Microphone : Gooseneck unidirectional avec bouton PTT (momentary)
• Affichage : 4.3" TFT couleur (zone selection, status, faults)
• Audio : Microphone sensitivity réglable, contrôle du volume, égalisation paramétrique configurable
• Entrées audio : Jack 3.5 mm pour microphone sans fil
• Réseau : PoE, double port Ethernet pour redondance
• Sécurité : AES67 pour audio, AES70 pour contrôle, support exigences cybersécurité IEC 62443
• Montage : Bureau, mural, encastré (panel)
• Indice de protection panneau avant : IP22 (min.)
• Fonctions supplémentaires : Chime intégré, mixing BGM & paging (ducking), concurrent paging, gestion conflits de zones
